110
When I/O3 is Mounted
No. Parameter name
Default value
(Reference)
Input range Unit Remarks
1 I/O port assignment type 0 0 ~ 20 0: Fixed assignment
121 Network attribute 2 C80000H 0H ~ FFFFFFFFH
Bits 8 to 11: Input port data select at I/O3 fieldbus link error
(0: Clear, 1: Hold)
225 Extension I/O control *9H Reference only
Bits 0 to 3: I/O2 Module Type
(0: Not mounted
1: CC-Link,
2: DeviceNet,
3: PROFIBUS,
4 to 6: System reservation
7: EtherNet/IP,
8: System reservation
9: PIO)
Bits 4 to 7: I/O3 Module Type
(0: Not mounted
1: I CC-Link,
2: DeviceNet,
3: PROFIBUS,
4 to 6: System reservation
7: EtherNet/IP,
8: System reservation
9: PIO)
* EtherNet/IP is unavailable for 2-piece mount at same time
233
Input port start number at I/O3
affixed assignment
160 -1 ~ 299 0 + (Multiple of 8) (Invalid if a negative value is set)
234
Output port start number at
I/O3 affixed assignment
460 -1 ~ 599 300 + (Multiple of 8) (Invalid if a negative value is set)
235 I/O3 error monitor 1 0 ~ 5
0: Do not monitor
1: Monitor
* Some exceptions apply.
* Bit 0 to 3 in I/O Parameter No. 225 varies the setting values depending on the status of I/O2 mount.
Chapter 3 Wiring3.3 IO Circuit
