Chapter 9 External Dimensions9.3 Option

354

[4] Side Slot Option

Front View of Type A

Side View of Type A (in common with Type C)

(29.5)

(97.5)

(127.5)

Note

• The side slit part is in common for Type A and Type C

16.5

7 3

7.3

4.3

4.5 1.5

Detail Diagram X

Scale 1 : 1
