IAI TTA Series - Name and Function of each Part

16
Name and Function of Each Part
<Front Side>
<Rear Side>
Z-Axis
Slider Position Adjustment
Volume (Z-Axis)
Grease Supply Inlet (Z-Axis)
Y-Axis
T-Grooves (×2)
T-Grooves (×2)
T-Groove
X-Axis
Front Panel
Grease Supply Inlet (Y-Axis)
Slider Position Adjustment
Volume (Y-Axis)
T-Grooves (×2)
T-Grooves (×2)
T-Groove
Rear Panel
Grease Supply Inlet (Z-
A
xis)
Slider Position Adjustment
Volume (X-Axis)
Grease Supply Inlet (X-Axis)
