Chapter 9 External Dimensions 9.3 Option
353
[3] Side Plate Option
Note • This drawing is a two-dimensional drawing from A-type side
plate option.
• It is assumed the X-axis slider is placed at the home position.
50
50
A=Bx50p
C-M4
Depth
8
Hole Positions for Standard Type
50
(H)
(D)
50
E=Fx50p
G-M4 Depth
8
M-M4
Depth
8
Hole Positions for Frame Position F1 Type
Hole Positions for Frame Position F2 Type
J=Kx50p
50
(N)
126
(157)
31
Frame Height (in common for all types)
ABCD
2020 250 5 12 45 3030 350 7 16 95 4040 450 9 20 145 5050 550 11 24 195
E FGH
2020 150 3 8 45 3030 250 5 12 95 4040 350 7 16 145 5050 450 9 20 195
J K MN
2020 50 1 4 45 3030 150 3 8 95 4040 250 5 12 145 5050 350 7 16 195
Models Models
Models
