Chapter 2 Installation2.3 How to Install
74
2.3 How to Install
This chapter explains how to install the actuator on your mechanical system.
2.3.1 Installation Orientation
Do pay attention to these items.
○: Available ×: Not available
Horizontal
Installation
Sideways
lnstallation
Ceiling Mount
Installation
○ × ×
Installation Orientation
Horizontal Installation Sideways lnstallation Ceiling Mount Installation
