IAI TTA Series - Ma Direction Moment Offset Datum Position and the Moment Direction of each Axis

Chapter 1 Specications Check 1.2 Mechanical Specications
53
1.2.7 Ma Direction Moment Offset Datum Position and the Moment Direction of Each Axis
• Work Moving Type
[Ma Direction Moment Offset Datum Position]
[Moment Direction of Each Axis] [Rotary direction for R-Axis]
X:Mb
Z:Mb
X:Ma
X:Mc
Y:Mb
Z:Mc
Y:Mc Z:Ma
Y:Ma
R:Mb
R:Ma
+ Direction
- Direction
X-Axis
X-Axis
Y-Axis
Z-Axis
R-Axis
Y-Axis
Z-Axis, R-Axis
Z-Axis
Y-Axis
X-Axis
Y-Axis
Ma Direction
Moment Offset
Datum Position
40
X-Axis Ma Direction Moment Offset Datum Position 49.7
Z-Axis
Ma Direction
Moment Offset
Datum Position
41
