Chapter 9 External Dimensions 9.1 Servo Motor Type, Pulse Motor Type (Battery-less Absolute Specication)
303
Chapter 9 External Dimensions
9.1 Servo Motor Type, Pulse Motor Type (Battery-less Absolute Specification)
9.1.1 Work Moving Type
[1] Two-Axis: X & Y-Axes 200mm Stroke
4.3
7.3
1.5
4.5
Xst:200
5
5
63110
178.5
57
317
495.5
20.5
ME
SE
ME
Y
60
362
340
32 165125
105
30
125
27.5
25
401
U
Yst: 200
5 5
55 70
205
483.7
112
76
(401)
ME ME
SE
S
70
80
70
30
60
2-
φ5
35
35
55
100
50
110
90
110
45
V
8
16.5
3
7
27.5
25
60
3.5 5
6-M5 Depth 7
4-M4 Depth 7
H7 Depth 5
Detail Diagram U (Detail of Y-Axis Slider)
(Reamer Pitch
Tolerance ±0.02)
T-Groove ×2
X View
(T-Groove on Side of Main Unit)
Profile of T-Groove
on Frame
X View
T-Groove ×2
HOME
T-Groove (Same Profile on Opposite Side)
<<Same Profile on Opposite Side>>
Dial for Y-Slider Position Tuning
Dial for X-Slider Position Tuning
Detail Diagram V (Grounding Screw)
Detail Diagram Y (Y slider side)
M4 for Grounding
SE: Stroke end
ME: Mechanical end
2-M3 Depth 5
6-M5 Depth 7
6-M4 Depth 7
Detail Diagram S (Detail of X-Axis Slider)
(Reamer Pitch
Tolerance ±0.02)
2-φ5 H7 Depth 5
HOME
Mass: 24kg
