Chapter 6 Error List6.3 Error List (MAIN Core)
240
6.3 Error List (MAIN Core)
(In the panel window, the three digits after “E” indicate an error number.)
Error No. Error name Description, action, etc.
A70 SCIF overrun error
Communication error. Check for noise, connected equipment and communication setting. (When
updating the application, connect to a PC and use IAI’s update tool.)
A71 SCIF framing error
Communication error. Check for noise, shorted/disconnected communication cable, connected
equipment and communication setting. (When updating the application, connect to a PC and use
IAI’s update tool.)
A72 SCIF parity error
Communication error. Check for noise, shorted/disconnected communication cable, connected
equipment and communication setting. (When updating the application, connect to a PC and use
IAI’s update tool.)
A73 IAI protocol header error
Communication protocol error. Check for noise and connected equipment. (When updating the
application, connect to a PC and use IAI’s update tool.)
A74 IAI protocol terminal ID error
Communication protocol error. Check for noise and connected equipment. (When updating the
application, connect to a PC and use IAI’s update tool.)
A75 IAI protocol command ID error
Communication protocol error. Check for noise and connected equipment. (When updating the
application, connect to a PC and use IAI’s update tool.)
A76 IAI protocol checksum error
Communication protocol error. Check for noise and connected equipment. (When updating the
application, connect to a PC and use IAI’s update tool.)
A77 Motorola S record type error The update program file is invalid. Check the file.
A78 Motorola S checksum error The update program file is invalid. Check the file.
A79 Motorola S load address error The update program file is invalid. Check the file.
A7A Motorola S write address over error The update program file is invalid. Check the file.
A7B Flash timing limit over error (Write) Error writing the flash ROM (When updating)
A7C Flash timing limit over error (Erase) Error erasing the flash ROM (When updating)
A7D Flash verify error Error erasing/writing the flash ROM (When updating)
A7E Flash ACK timeout Error erasing/writing the flash ROM (When updating)
A7F Head sector number specification error Error erasing the flash ROM (When updating)
A80 Sector count specification error Error erasing the flash ROM (When updating)
A81
Write-destination offset address error (Odd-numbered
address)
The address written during flash ROM write (when updating) is invalid. Check the update program
file.
A82
Write-source data buffer address error (Odd-numbered
address)
Error writing the flash ROM (When updating)
A83 Invalid code sector block ID error
The flash ROM is new, or the program currently written to the flash ROM is invalid because the
last update was aborted. The ROM can be updated without problem.
A84 Code sector block ID erase count over The number of times the flash ROM was erased exceeded the allowable count.
A85 FROM write request error before erase is complete
When updating, a flash-ROM write command was received before a flash-ROM erase command.
Confirm that the update program file is valid and then perform update again.
