Chapter 4 Operation4.3 Program Operation
132
Caution: • When Input Function Select 000 (Start) is assigned to another input port, “Start
Switch” on the front panel would not work as “Program Start Signal”.
• When Input Function Select 007 to 013 (Digi-Switch) are assigned to other input
ports, “Program Switch” on the front panel would not work as “Program Start
Indication Program Number”.
RDY output
(output from the TTA)
Program No.
(output from the host)
Program start
(output from the host)
Program
Program execution
1)
2)
4)
3)
Program number
6)
To Next Page
