About Safety Protection Fence
Considering safety, it is recommended to have a safety protection fence to prevent possible danger.
For Machinery Directive (2006/42/EC) in EU Directives, equip with safety protection fence.
Use a system I/O connector at the entrance of the safety protection fence to equip with an interlock
system which makes the emergency stop works when the entrance is opened, and make sure to avoid
entering from nowhere else but the entrance.
Rear Panel Side of Main Body Front Panel Side of Main Body
Detail Power Supply Part
Scale 1:4
Have an enclosure around the power
supply switch and the power supply
inlet so they can be operated from
outside the fence.
Detail Emergency Stop Button Part
Scale 1:4
Have an enclosure around the
emergency button so it can be
operated from outside the fence.
Entrance
Power Supply Switch
Power Supply Inlet
Emergency Stop Button
To Next Page
