Chapter 6 Error List 6.1 Error Level Control
205
Program run (Application only)
Error level
System error
assignment source
Error No.
(HEX)
Display
(7-segment
display, etc.)
Error list
(Application
only)
Error LED
output
(MAIN only)
Other parameter No. 4 = 0 Other parameter No. 4 = 1
Error reset
(Application
only)
Remarks
Main application B00 to B9F
Main core BA0 to BBF
PC BC0 to BDF
TP BE0 to BFF
Main application C00 to CCF
Main core CD0 to CDF
PC CE0 to CEF
Operation-
cancellation
level
TP CF0 to CFF
The program in which the error
generated will be cancelled.
(Except for axis errors, a
cancellation factor is present only
for the moment the error occurs.)
* However, in the case of an error
requiring servo OFF or all-axis
servo OFF, all programs other
than the “I/O processing program
at operation/program abort” will
be cancelled. (X-SEL J/K Main
application version 0.17 or later)
All programs other than the
“I/O processing program at
operation/program abort”
will be cancelled. (Except
for axis errors, a
cancellation factor is
present only for the
moment the error occurs.)
Enabled
Errors affecting
operation. The
system will attempt
to reset minor errors
below this level
using an auto-reset
function via external
active command
(SIO/PIO)
(application only).
Main application 500 to 5CF
Main core -
PC
PC (Update tool)
TP
Main application 600 to 6CF
Main core -
PC 6D0 to 6DF
PC (Update tool) 6E0 to 6EF
TP 6F0 to 6FF
Main application D00 to D8F
Main core D90 to DAF
PC DB0 to DCF
PC (Update tool) DD0 to DDF
TP DE0 to DFF
Main application E00 to E8F
Main core E90 to EBF
PC EC0 to EDF
Cold start
level
TP EE0 to EFF
(Core only)
The program in which the error
generated will be cancelled.
* However, in the case of an error
requiring drive-source cutoff,
servo OFF or all-axis servo OFF
(initialization error, power error,
etc.), all programs other than the
“I/O processing program at
operation/program abort” will be
cancelled.
All programs other than the
“I/O processing program at
operation/program abort”
will be cancelled.
Not
enabled.
The controller
power must be
reconnected (MAIN
only).
(The CPU and OS
will run properly.)
To Next Page
