9-32 FLIGHT CONTROLS / ROLL CONTROLS
ICON A5 / MAINTENANCE MANUAL CHANGE C3
RELATED INFORMATION:
"Baggage Floor Removal" on page 3-41
"Seat Back Removal" on page 3-50
"Seat Pan Removal" on page 3-52
"Cockpit Floor Board Removal" on page 3-46
"Baggage Sidewall Panel Removal" on page 3-43
"Headliner Removal" on page 3-37
"Inspect Control Cables" on page 9-8
9.4.4.3 Install Roll Cables
Use the following task to install the upper and lower control cables.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
Flight Control Cable Tensiometer
3xDIA .185” Rig Pins
1xDIA .250” Rig Pins
Parts Required
2xICA008437 (CONTROL CABLE, ROLL, FUSELAGE)
2x ICA012104 (CLIP, LOCKING, TURNBUCKLE .042”)
2x MS21256-1 (CLIP, LOCKING, TURNUCKLE)
12x MS25665-151 (PIN, COTTER, CRES, .063” x .500”)
1x ICA005909 (CONTROL CABLE, ROLL, FUSELAGE, UPR)
2x-4x MS21043-3 (LOCKING NUT, 10-32)
Aircraft System and Number
06-Flight Controls
Consumables
None
Install Lower Roll Cable:
