HORIZONTAL TAIL / HORIZONTAL TAIL GENERAL MAINTENANCE 12-13
CHANGE C1 ICON A5 / MAINTENANCE MANUAL
CHAPTER 12
RELATED INFORMATION:
"Removal and Installation of Inspection Panels and Fairings" on page 3-34
"Horizontal Tail Installation" on page 12-13
"Elevator Pushrod Removal" on page 12-10
"Air Rudder Removal" on page 12-9
"Rigging Pitch Controls" on page 9-46
"Remove Horizontal Tail Tip Lock Switches" on page 12-6
"Install Horizontal Tail Tip Lock Switches" on page 12-16
12.3.1.5 Horizontal Tail Installation
Use these instructions to install the horizontal tail.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
09—Horizontal Tail
Consumables
None
For the steps involved in removing the horizontal tail, See “Horizontal Tail Removal” on page 12-11.
TASK INSTRUCTIONS:
1. Verify that the final pitch pushrod and air rudder are not installed. The pushrod passes through
the horizontal tail aft attach fitting and so it cannot be in place during horizontal tail installation.
2. Lift horizontal tail into position on top of the vertical tail and support it just above its final position
with padded scaffolding, ladders, or with two helpers.
3. Connect the multi-pin wire connector and coaxial cable connectors at the vertical tail/horizontal
tail joint.
4. Lower the horizontal tail into position so that the composite fitting projecting down from the hori-
zontal tail likes flush with the vertical tail spar. Use care to avoid pinching the electrical cables;
feed slack in cables through hole in top vertical tail rib.
