Fuse ID Description Sub Components Reference
INSTR 3 Secondary Power Annunciator panel “Annunciator Panel Function” on
page 13-38
DAC “DAC Memory Unit” on page
13-65
“System Wiring Diagram, Engine
Interface” on page 6-8
“System Wiring Diagram,
Instrument Signals” on page 6-20
Engine relays “System Wiring Diagram, Engine
Interface” on page 6-8
ENG BKUP Engine Backup
Power
Engine “System Wiring Diagram, Engine
Interface” on page 6-8
12V/USB Outlets 12V outlet “System Wiring Diagram, Outlets”
on page 6-26
USB outlet “System Wiring Diagram, Outlets”
on page 6-26
INT LIGHTS Interior Lights Lighting controller “System Wiring Diagram, Interior
Lighting” on page 6-21
Dome light “System Wiring Diagram, Interior
Lighting” on page 6-21
STROBE/NAV Anti—Collision
Lights—Position
RH ACL-position “System Wiring Diagram, Exterior
Lights” on page 6-12
LH-ACL-position “System Wiring Diagram, Exterior
Lights” on page 6-12
Strobe controller “System Wiring Diagram, Exterior
Lights” on page 6-12
WATER RUDR Water Rudder Actuator “Water Rudder” on page 11-11
“System Wiring Diagram, Water
Rudder” on page 6-29
