13-22 INSTRUMENTS (AND AVIONICS) / INSTRUMENTS AND AVIONICS GENERAL MAINTENANCE
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 13
INSTR 1 Instruments Gauges “System Wiring Diagram,
Instrument Signals” on page 6-20
Backlight
potentiometer
“System Wiring Diagram,
Instrument Lighting” on page 6-19
Hour meter “System Wiring Diagram, Hour
Meter” on page 6-18
Transponder “Transponder” on page 13-8
“System Wiring Diagram, Mode
C” on page 6-25
TRIM Pitch Trim Actuator “Pitch Trim Actuator” on page
9-53
“System Wiring Diagram, Control
Sticks, Pitch Trim” on page 6-6
MAIN GEAR Main Landing Gear Actuator “Main Landing Gear” on page
14-37
“System Wiring Diagram, Landing
Gear” on page 6-22
MASTER Master Contactor Contactor “System Wiring Diagram, Engine
Interface” on page 6-8
HEAT Cabin Heat Fan “Cabin Heater” on page 7-3
“System Wiring Diagram, Heater”
on page 6-17
Solenoid valve “System Wiring Diagram, Heater”
on page 6-17
Fuse ID Description Sub Components Reference
