INSTRUMENTS (AND AVIONICS) / ELT 13-61
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
14. If ground wires have not been bonded:
a. Lightly abrade cowl surface inside tape squares and clean with isopropyl alcohol. Secure
ground wires to inside surface of engine cowl using CB200 with nominal diameter of 1/2”.
FIGURE 13-17
BOND GROUND WIRES TO COWL SURFACE
b. Allow adhesive to become tacky before removing masking tape. Use caution to ensure
wires do not get pulled out of the adhesive. Allow 30 minutes for the adhesive to cure.
15. Reinstall the top engine cowling. (See “Install Engine Cowlings” on page 16-16.)
VERIFICATION METHOD:
Perform ELT unit self-test according to SELF TESTS of Section 9 of ACK Technologies Inc. Model
E-04 ELT Installation/Operation Manual, or See “ELT Battery Self Test” on page 13-47.
RELATED INFORMATION:
"Remove Engine Cowlings" on page 16-13
"Install Engine Cowlings" on page 16-16
"ELT Battery Self Test" on page 13-47
