LANDING GEAR / BRAKE LINE 14-25
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
RELATED INFORMATION:
"Wheel and Brake System Maintenance" on page 14-18
"General Brake Line Termination Procedure" on page 14-29
14.5.1.1.3 Aft Lines Replacement
Use the following procedure to replace the aft lines.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
HDB01 Stainless Steel Braided Brake Hose
HYD-008P B-nut or HEA01 Banjo fittings as required
T25F-C0 Spiral Wrap
TY24MX Cable Tie
Aircraft System and Number
11—Landing Gear
Consumables
F4TAPEBLACK Silicone Tape
Smooth-On Sil-Poxy
NOTE: The two aft brake lines (Left and Right) that run between he brake
calipers and the parking brake valve are nearly identical, differing
only in their length and where they are attached and secured. Use
the procedure below to replace either of them, paying attention to
the differences where noted.
1. Use a 7/16 wrench to hold the AN816-3D fitting on the aft port of the parking brake valve, then a
1/2 wrench to disconnect the B-nut of the aft brake line at the parking brake valve. Cap or plug
the openings to minimize fluid loss.
2. Use a 14mm wrench to remove the banjo bolt and two copper washers at the MLG brake caliper.
3. Cut and remove all the cable ties holding the brake line to the structure.
