14-48 LANDING GEAR / MAIN LANDING GEAR
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 14
6. Remove the four AN4C16A bolts that secure the MLG axle to the MLG leg. Remove the reinforce-
ment plate from the MLG leg. Retain hardware for reinstallation.
7. Separate the axle from the leg. Remove the countersunk screws on the inboard side of the axle
to disconnect the brake caliper from the axle. It is permissible for the caliper to dangle from the
landing gear leg. Retain hardware for reinstallation.
VERIFICATION METHOD:
Task is complete when wheel and axle are fully removed from the leg.
RELATED INFORMATION:
"Main Landing Gear (MLG) Boot Removal" on page 14-41
"Empty Weight and CG Measurement While on Jackpoint Scales" on page 3-32
14.6.1.7 Main Landing Gear (MLG) Wheel and Axle Installation
Use the following procedure to install the MLG wheel and axle.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
Cotter Pin, .312
Aircraft System and Number
11—Landing Gear
Consumables
Tef-Gel
®
MOLYKOTE™
TASK INSTRUCTIONS:
1. Attach the brake caliper to the main landing gear axle using the retained countersunk screws.
Coat the screws with a thin layer of Tef-Gel
®
on installation, torque them to 88 in-lb.
