16-42 PROPULSION / ENGINE
ICON A5 / MAINTENANCE MANUAL CHANGE C2
FIGURE 16-28
FLAT HEAD SCREWDRIVER POSITIONED INTO THE CONNECTORS FOR REMOVAL.
6. Clean the electrical connections on the primary side (spades on coil pack) using ISOPROPYL
ALCOHOL. Let it dry.
NOTE: Use sanding paper if necessary to clean the connections.
7. Apply bead of GREASE, DIELECTRIC on the four spade connectors to seal and lubricate as
necessary.
8. Reconnect the connectors to the respective coil pack terminals and tighten the connections if
loose.
9. Replace the M5 Allen screws and torque to 53 in-lb.
10. Replace spiral wrap as required.
11. Reverse engine cowl instructions to install cowl. (See “Remove Engine Cowlings” on page 16-13.)
VERIFICATION METHOD:
Complete the engine test run. (See “Engine Test Run” on page 16-7.)
