PROPULSION / ENGINE 16-83
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
11. Run the engine and check for good oil pressure and no leaks. Replenish the oil level as required.
12. Install the engine top cowling. (See “Remove Engine Cowlings” on page 16-13.)
VERIFICATION METHOD:
The procedure is complete when the oil cooler and thermostat have been installed and the engine
check shows good oil pressure and no leaks.
RELATED INFORMATION:
"Remove Engine Cowlings" on page 16-13
16.1.9 Fuse Box
16.1.9.1 Fuse Box Description
The fuse box contains a fuse panel for the engine and two rectifier regulators on either side.
16.1.9.2 Fuse Box Diagram/Schematic
FIGURE 16-48
FUSE BOX
