16-106 PROPULSION / PROPELLER
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 16
NOTE: Each aircraft has a unique set of six Torx fasteners and washer
stacks. The fasteners and washer stacks must be reinstalled in the
starting condition to maintain proper propeller balance.
3. Slide the spinner dome off in the aft direction.
VERIFICATION METHOD:
This task is complete when the spinner dome has been removed.
RELATED INFORMATION:
"Condition and 100-Hour Inspection—Engine and Propeller" on page 3-21
"Balance Propeller" on page 16-95
16.2.5.1.2 Install Spinner Dome
Use the following task to reinstall the spinner dome.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
13—Propulsion
Consumables
Tef-Gel
®
TASK INSTRUCTIONS:
1. Slide dome onto backplate and line up orientation marks made during removal.
2. Install the six Torx fasteners with Tef-Gel
®
and washer stacks in their original unique configura-
tion. Tighten Torx fasteners into locking nut plates and torque to 26 in/lbs with a T20 Torx driver.
