Image 7.43: Test signal generator for square signal
ID No.: 0842.26B.5-01Date: 09.2020
ServoOne- Device Help
164
7 Control
ID
Parameter /
Setting
Function Info
1500
SCD_TSIG_
Con
Controlwordoftestsignal
generator
Theparameterisresettothe
value0oncompletionofthe
stopprocedure.
 OFF(0)
Testsignalgenerator
deactivated

 Stop(1) Stoptestsignal 
 Start(2) Starttestsignal 
 STOP-Cycle(3)
TGstopsatendofcurrent
squarecycle

 Stop-Zero(4)
TGstopsnexttime
referencevaluepasses
throughzero

1501
SCD_TSIG_
OutSel
Testsignalgenerator
outputselector

 OFF(0) Notused 
 isdref(1) Flux-formingcurrent 
 mref(2) Torque 
 sref(3) Speed 
 epsref(4) Position 
 sramp(5) Speed(ramp) 
 ISQREF(6) q-currentreference 
 ISDQREF(7)
d-currentq-current
reference

Table 7.38: Parameters of test signal generator for square and sine signal
