Setting Name Description
0 ANA0
AnalogueinputISA00(CON_ANA_Isaf
[0])
1 ANA1
AnalogueinputISA01(CON_ANA_Isaf
[1])
2 FIELDBUS
Fieldbusparameter.
CON_PRC_ACTVAL_FIELDBUSP
2677
3
REFSPEED
Current speed (internal) Current speed
from encoder for unfiltered speed control
4 REFPOS
Actualposition(internal)
Currentpositionfromencoderfor
unfilteredpositioncontrol
5 ISQREF_SCON
Presentsetpointforcurrentfromspeed
controller
6
Reserved Special hardware required
7
Reserved Special hardware required
8
P_ACT
Actual pressure.
Any analogue input (function selector for
analogue inputs set to a value of -13)
9 IEA04
AnalogueinputIEA04fromMultiI/O
module(TOPT_MIO_AIN_Val_Scaled
[0])
Table 7.44: Selector for actual value (P 2668[0])
ID No.: 0842.26B.5-01Date: 09.2020
ServoOne- Device Help
171
7 Control
Setting Name Description
10 IEA05
AnalogueinputIEA05fromMultiI/O
module(TOPT_MIO_AIN_Val_Scaled
[1])
11 SPEED
Actual speed normalized. Speed in user
units.
12 POS
Actual position normalized. Position in
user units
13 P2981 MappableparameterP-2981*
14 P2982 MappableparameterP-2982*
15 P2983 MappableparameterP-2983*
16 P2984 MappableparameterP-2984*
* See Section "Mapping parameters and scope values" on page 172
Table 7.44: Selector for actual value (P 2668[0]) (continue)
NOTE
If the actual value source is selected, the respective input must also have
a function assigned to it.
see also section "Function selectors" on page317
The selected actual value will be output in P2673[0] - CON_PRC_RAW_ACTVAL.
In addition, a configurable offset, P2669[0] - CON_PRC_ACTOFFSET, can be
superimposed on the actual value. The actual value can be smoothed with a
configurable PT-1 filter. To use this option, the user can use P2670[0]- CON_PRC_
ACTTF to set a filter time in milliseconds. If the filter time is set to 0ms, the filter will
be disabled. Moreover, the filtered actual value can be scaled with P2671[0] -
