In addition to the process controller status word, bit 8 of the device status word,
P702[0] - MON_State, will be set when the setpoint is reached. P2679[0] - CON_
PRC_RefReached can be used to configure the “Reference value attained” window
for this purpose. Bit 8 will be set to TRUE if the process controller’s deviation is less
than 50% of the configured “Reference value attained” window.
7.10.2.2Referencevalues
The process control circuit setpoint can be selected via pre-defined setpoint sources.
P2683[0] - CON_PRC_REFSEL can be used to select these setpoint sources.
Setting Name Description
0 USER
UserinputviaCON_PRC_REFVAL_
User - P2684
1 RPDC
Setpoint for rack and pinion control.
Automatic input of transmitted RPDC
current value
2
ISA00

Setpoint via analogue input ISA00.
Analogue input ISA00 (CON_ANA_Isaf
[0])
3
ISA01

Setpoint via analogue input ISA01.
Analogue input ISA01 (CON_ANA_Isaf
[1])
4
Reserved Special hardware required
5
Reserved Special hardware required
Table 7.43: Selector for reference value source (P 2683[0])
ID No.: 0842.26B.5-01Date: 09.2020
ServoOne- Device Help
170
7 Control
Setting Name Description
6
P_REF
Reference pressure.
Any analogue input (function selector for
analogue inputs set to a value of -14).
7 P2981 MappableparameterP-2981*
8 P2982 MappableparameterP-2982*
9 P2983 MappableparameterP-2983*
10 P2984 MappableparameterP-2984*
* See Section "Mapping parameters and scope values" on page 172
Table 7.43: Selector for reference value source (P 2683[0]) (continue)
NOTE
If the target value source is selected, the respective input must also have
a function assigned to it.
see also section "Function selectors" on page317
Once the setpoint source is selected, the process controller setpoint can be set with
P2666[0] - CON_PRC_REFVAL. This setpoint can then be scaled further with
P2667[0] - CON_PRC_REFSCALE in order, for example, to incorporate decimal
places and/or unit conversions.
7.10.2.3Actualvalues
The process control circuit actual value can be selected via a number of pre-defined
actual value sources. P2668[0] - CON_PRC_ACTSEL can be used to select these
actual value sources.
