Keba ServoOne User Manual

P No. Index P Name / Setting Unit Function
 0 Type  
  Off(0)  Nomotortemperaturesensor
  KTY(1)  KTY84-130Sensor
  PTC(2)  PTCsensor(three)withshortcircuitmonitoring
below50ohmsorhardwaredetection
  TSS(3)  Switch(Klixon)
  PTC1(4)  PTCsensor(one)withoutshortcircuit
monitoring
  PT100(5)  PTC100inlinewithDINEN60751
  NTC220(6)  NTCSensor220kOhm
1)
  NTC1000(7)  NTCSensor1000kOhm
  NTC_K227(8)  NTCSensorK22732kOhm
  KTY83-110(9)  KTY83-110Sensor
  NTC50(10)  NTCsensor50kOhm
  NTC10(11)  NTCSensor10kOhm
  PTC2(12)  PTCsensor(simple)withshortcircuit
monitoringunder5ohms
  PT1000(13)  PT1000Sensor
2)
 PT1000-2(14)  PT1000-2sensor,Rxvalueviainternaltable
withmeasurementvalues(fromthe
application)
  PT1000-3(15)  Rxvaluesovercalculatedvalues(fromcircuit
diagram)(notable)
 1 Contact  Terminationvariant
  X5(0)  ConnectionofthesensortoterminalX5
  X6/7(1)  Sensorconnectionisroutedinencodercable
  X5_X6/7(2)  Useofbothinputspossible
  X8(3)  X8connectortemperaturesensor(techopt
module)
  X5_X8(4)  X5andX8connectortemperaturesensor(tech
optmodule)
 2 Typeextended  
  Off(0)  Nomotortemperaturesensor
  KTY(1)  KTY84-130Sensor
Table 5.7: “Temperature monitoring” parameters (continue)
ID No.: 0842.26B.5-01Date: 09.2020
ServoOne- Device Help
41
5 Motor
P No. Index P Name / Setting Unit Function
  PTC(2)  PTCsensor(three)withshortcircuitmonitoring
below50ohmsorhardwaredetection
  TSS(3)  Switch(Klixon)
  PTC1(4)  PTCsensor(one)withoutshortcircuit
monitoring
  PT100(5)  PTC100inlinewithDINEN60751
1)
 NTC220(6)  NTCSensor220kOhm
1)
1)
 NTC1000(7)  NTCSensor1000kOhm
1)
 NTC_K227(8)  NTCSensorK22732kOhm
  KTY83-110(9)  KTY83-110Sensor
  NTC50(10)  NTCsensor50kOhm
  NTC10(11)  NTCSensor10kOhm
  PTC2(12)  PTCsensor(simple)withshortcircuit
monitoringunder5ohms
  PT1000(13)  PT1000Sensor
2)
 PT1000-2(14)  PT1000-2sensor,Rxvalueviainternaltable
withmeasurementvalues(fromthe
application)
  PT1000-3(15)  Rxvaluesovercalculatedvalues(fromcircuit
diagram)(notable)
    
733  MON_MotorI2t  I
2
tcharacteristicsetting
 0 INom % Ratedcurrentofthemotor
 1 I0 % Firstcurrentinterpolationpointofmotor
protectioncharacteristic:Maximum
permissiblestandstillcurrent
 2 I1 % Secondcurrentinterpolationpointofmotor
protectioncharacteristicreferredtomaximum
characteristiccurrent
 3 F1 Hz Firstfrequencyinterpolationpointofmotor
protectioncharacteristic
 4 FNom Hz Ratedfrequency
 5 IMax % Maximumoverloadcurrentinrelationtothe
ratedcurrentofthemotor
 6 Time s Timeforwhichthemaximumcurrentmaybe
connected
