P No. Index P Name / Setting Unit Function
 7 Ttherm s Setthermaltimeconstantinseconds
735 0 MON_MotorI2tType  Motorprotectionmodule.SelectionofI2T
monitoringmethod
  Off(-1)  Protectiondisabled
  FREQU(0)  Motorfrequency-dependentevaluationi(f),
defaultsetting
  THERM(1)  Evaluationwiththermaltimeconstanti
Tth
.The
thermaltimeconstantissetviaparameter
P 733[7]in[s].Theshut-offthresholdbasedon
measurementtolerancesis110%ofthe
nominalvalue.
Table 5.7: “Temperature monitoring” parameters (continue)
NOTE
l WithaServoOnejuniorthetemperaturesensorcablecanbe
connectedtobothX6andX7.
l
1)
DoesnotapplytotheServoOnejunior
l
2)
WithServoOnejunior
The following table provides an overview of the selection options for sensor types
with P 732[0] as well as the connection options for the plug-in connectors X5, X6, X7
and X8 (Tech. option) for ServoOne and ServoOnejunior.
ID No.: 0842.26B.5-01Date: 09.2020
ServoOne- Device Help
42
5 Motor
ServoOne
ServoOne junior / Ser-
voOne Safety
Sensor
type
Parameters Plug-inconnector  Plug-inconnector
X5 X6 X5 X6
(1)
X7
(1)
X8
(4)
KTY P732[0]=1,9 X X — X X
PTC P732[0]=2,4,12 X X X X X
TSS P732[0]=3 X X X X X
NTC P732[0]=6,7,8,10,11
2)
— X — X —
PT P732[0]=5
3)
,13 X X — X X
1) X6/X7 bridged internally
2) not ServoOnejunior
3) only ServoOnejunior
4) Tech-opt card X8-HDSL: all settings P732[0].Type = 1..13 are possible! (with HDSL firmware (v3.44.20-xx))
Table 5.8: Temperature sensor connections with plug-in connectors.


