MD-11 Flight Crew Operations Manual
k
Warning and Alerting -
Description and Operation
Warn.10.11
SD Status Page
The STATUS page displays a list of all alerts included on the systems pages and
is selected by pushing the STATUS switch on the SDCP. The alerts are shown in
three columns in the same format as on the EAD. The alerts are grouped per
system in the same order as the cue switches on the SDCP and the reminder
messages on the EAD (ENG, HYD, ELEC, AIR, FUEL, CONFIG, and MISC). A
separate section for maintenance alerts is after the MISC system alerts. This
section is titled MAINT. MAINT alerts appear only on status page one and can
only be level 1. Within each system group, the alerts are grouped by level and
appear in the same order as they appeared on the EAD. Above each group of alerts
appears the system label, preceded by a blank line if not at the top of the page. This
system label will appear as a place holder even if no alerts are associated with that
system. This page and all subsequent pages can display up to 51 alerts. When there
are additional pages, the message PRESS STATUS AGAIN TO CONTINUE will
appear at the bottom of the page if there are additional pages.
LB1-3-0190
ALERT LEVEL 2
STATUS
ENG
HYD
ELEC
AIR
ALERT LEVEL 2
FUEL
ALERT LEVEL 1
ALERT LEVEL 1
MISC
CONFIG
ALERT LEVEL 2
ALERT LEVEL 1
MAINT
October 02, 2006
