MD-11 Flight Crew Operations Manual
k
Warning and Alerting -
Description and Operation
Warn.10.12
SD Miscellaneous Page
The miscellaneous system page is selected to appear on the SD by pushing the
MISC switch on the SDCP. The miscellaneous system page displays alerts and
consequences for various uncategorized systems in text form only. The
consequences are grouped with the alerts in the same manner as the consequences
page. The first miscellaneous systems page may have a maximum of 17 alerts and
17 consequences.
Additional pages may be made available for the display of consequences and may
display up to 17 alerts and 17 consequences. When additional pages are required,
the message PRESS MISC AGAIN TO CONTINUE will appear at the bottom of
the page.
The miscellaneous page is for alerts (levels 3, 2, and 1 only) and consequences
(levels 3 and 2).
Central Aural Warning System (CAWS)
The CAWS function provides aural warnings of an unsafe condition or situation.
The CAWS consists of a controller installed in the avionics rack. The controller
receives and process signals from selected sources for activation of the
appropriate aural warnings. The CAWS operates on 28-volt dc power.
An additional interface links the controller to the Display Electronic Units (DEU)
that send data to the Display Units (DU) in the cockpit. A CAWS FAULT alert
will be displayed when a fault is detected in the CAWS.
LB1-3-0191
ALERT LEVEL 3
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
ALERT LEVEL 2
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
ALERT LEVEL 2
MISCELLANEOUS (1/2)
CONSEQUENCES
PRESS MISC AGAIN TO CONTINUE
