Kyocera TASKalfa 8002i - Page 1356

2WA/2NJ/2RK
7-496
(1-5) C0830: FAX PWB flash program area checksum error
The program stored in the flash memory on the FAX PWB is broken so it cannot perform.
(1-6) C0870: PC FAX Image data transmission error
Data was not properly transmitted even if the specified times of retry were made when the large volume data
is transmitted between the FAX PWB and the main PWB.
4 Replacing the SSD The SSD (FAX image stor-
age) is faulty.
Replace with the new SSD. Detaching
and reat-
taching the
SSD
5 Replacing the main PWB The main PWB is faulty. Replace the main PWB. Detaching
and reat-
taching the
main PWB
Step Check description Assumed cause Measures Reference
1 Firmware upgrade The firmware is not the lat-
est version.
Upgrade the fax firmware to
the latest version.
Firmware
Update
2 Checking the FAX PWB The FAX PWB is not prop-
erly connected.
Turn the power switch and
the main power switch off .
After 5s passes, reattach the
FAX PWB and turn the main
power switch and the power
switch on.
FAX Instal-
lation
Guide
3 Initializing the fax The data in the FAX PWB
is faulty.
Execute U600 to initialize the
FAX.
Executing
U600
4 Replacing the FAX PWB The FAX PWB is faulty. Replace the FAX PWB. FAX Instal-
lation
Guide
Step Check description Assumed cause Measures Reference
1 Resetting the main power The FAX PWB does not
operate properly.
Turn the power switch and
the main power switch off .
After 5s passes, reattach the
FAX PWB and turn the main
power switch and the power
switch on.
FAX Instal-
lation
Guide
Step Check description Assumed cause Measures Reference
