Kyocera TASKalfa 8002i

2WA/2NJ/2RK-1
8-35
*: *The voltage value depends on the destination
YC6 6 GND - - Ground
7 GND - - Ground
8 GND - - Ground
YC7 1 +24V4 O DC24V DC24V power output
2 GND - - Ground
3 GND - - Ground
4 +24V4 O DC24V DC24V power output
5 +24V4 O DC24V DC24V power output
6 GND - - Ground
YC8 1 GND - - Ground
2 +5V0 O DC5V DC5V power output
3 GND - - Ground
4 +5V0 O DC5V DC5V power output
5 GND - - Ground
6 +5V0 O DC5V DC5V power output
7 GND - Ground
8 +5V0 O DC5V DC5V power output
9 GND - - Ground
10 +5V0 O DC5V DC5V power output
11 GND - - Ground
12 +5V0 O DC5V DC5V power output
YC9 1 POWER_OFF I DC0V/3.3V Sleep signal
2 DRM HEATER
REM
O DC0V/3.3V Drum heater: On/Off
3 GND - - Ground
4 AC DETECTOR - - Not used
Connec-
tor
Pin Signal I/O Voltage Description
