2WA/2NJ/2RK-1
8-111
YC7 5 GND - - Ground
6 PHPES REM I DC0V/3.3V PH paper edge sensor: On/Off
7 PHMOT REM O DC0V/3.3V PH motor: On/Off
8 PU RDY I DC0V/3.3V Ready signal
9 PU SEL O DC0V/3.3V Select signal
10 PU CLK O DC0V/3.3V Clock signal
11 PU DI I DC0V/3.3V Serial communication data signal input
12 PU DO O DC0V/3.3V Serial communication data signal output
YC8 1 GND - - Ground
2 24V2 O DC24V DC24V power output
YC9 1 BF DI I DC0V/3.3V Serial communication data signal input
2 BF DO O DC0V/3.3V Serial communication data signal output
3 BF CLK O DC0V/3.3V Clock signal
4 BF SEL O DC0V/3.3V Select signal
5 BF RDY I DC0V/3.3V Ready signal
YC10 1 3.3V O DC3.3V DC3.3V power output
2 GND - - Ground
3 GND - - Ground
4 5V O DC5V DC5V power output
5 GND - - Ground
6 GND - - Ground
7 24V2 O DC24V DC24V power output
8 24V2 O DC24V DC24V power output
YC12 1 ST MOV MOT 2B O DC0V/24V(pulse) DF slide motor control signal
2 ST MOV MOT 1B O DC0V/24V(pulse) DF slide motor control signal
3 ST MOV MOT 2A O DC0V/24V(pulse) DF slide motor control signal
4 ST MOV MOT 1A O DC0V/24V(pulse) DF slide motor control signal
5 EJECT MOT 2B O DC0V/24V(pulse) DF eject motor control signal
6 EJECT MOT 1B O DC0V/24V(pulse) DF eject motor control signal
7 EJECT MOT 2A O DC0V/24V(pulse) DF eject motor control signal
8 EJECT MOT 1A O DC0V/24V(pulse) DF eject motor control signal
9 MIDDLE MOT 2B O DC0V/24V(pulse) DF middle conveying motor control signal
10 MIDDLE MOT 1B O DC0V/24V(pulse) DF middle conveying motor control signal
Connec-
tor
Pin Signal I/O Voltage Description
