Kyocera TASKalfa 8002i - Page 162

2NJ/2RK
2-113
6. Connect the connector (b) of the cassette heater (a) to the connector (c) of the paper feeder rear frame.
7. Pass through the cassette heater wire (d) in three wire saddles (e).
Figure 2-217
8. Insert two hooks (b) of the heater cover (a) into the hole.
9. Reattach the heater cover (a)with one screw (c)(M4x8).
Figure 2-218
b
a
c
e
e
d
a
b
c
a
