Kyocera TASKalfa 8002i

2WA/2NJ/2RK
4-67
7. Remove two stop rings A (b) from the
PF paper feed shaft (a).
8. Remove two stop rings B (c) and slide
the joint (d).
Figure 4-92
9. Slide two bushings (b) at the both sides
of the feed roller holder (a).
10. Remove the feed roller holder (a) and
spring (d) upward from the PF feed unit
(c).
Figure 4-93
c
b
b
a
d
14j0106
a
b
c
b
d
14j0107
