Working sequence in automatic mode
Operating Manual 7.1 Rev.: 18.06.2008 101
5.5.2 Activating data
During a production phase, only activated data elements will be pro-
duced.
You can activate data elements in the following ways:
• All data
• Areas of data elements
– including all associated segments
– With the data segments located in the selection area only
• Data segments by index number
Note: BoardMaster assists you in selecting and activating/deactivating the
desired data by colour-coding it.
Activating all data
1. Click on All+ to activate all data.
[ ] All data is highlighted in colour and is activated for production.
Activating areas of data elements
1. To activate data elements within an area including all associated
segments:
– Click on the Add lines button.
– Draw up the desired area with the left mouse button pressed.
– Click on the + button.
All data segments within the selected area and all associated segments
are activated.
2. To activate all data segments within an area only:
– Click on the Add segments button.
– Draw up the desired area with the left mouse button pressed.
– Click on the + button.
All data segments within the selected area are activated.
Note: Repeat one of the procedures to activate further data ranges.
