Technical data
Operating Manual 7.1 Rev.: 18.06.2008 145
9. Technical data
ProtoMat
®
S62
Operating voltage
(manually changeable)
220–240V; 50Hz –60Hz
110V–120V; 50Hz –60Hz
Power consumption 200 W
Weight (without/with cover) 55 kg (121 lb)
Dimensions (W × H × D) 670 mm × 540 mm × 760 mm (26.4” × 21.3” × 29.9”)
Operating temperature 15 °C – 25 °C (59 °F – 77 °F)
Allowed humidity 60 % max.
Airborne noise at the workstation 71dB (A)
Milling/drilling spindle
Speed
3-phases motor
62,000 U/Min. max., software controlled
Travel speed: 150 mm/s (6“/s) max.
Drilling performance: 150 strokes/min. max.
Tool change: Automatic (10 stations)
Tool holder: 3.175 mm (1/8 ") collet chuck
X/Y-drive: 3-phases-step motors
Z-drive: Step motor
Milling depth adjustment: Manually
Traversing range of the mil-
ling/drilling head (X × Y × Z):
Basic version: 305 mm × 229 mm × 38 mm (9” × 1” × 1.5”)
With vakuum table: 305 mm × 229 mm × 25 mm (9” × 1” × 1”)
Resolution (X/Y): 0.25 µm (0.01 Mil)
Reproducibility: +/- 1 µm (0.04 Mil)
Positioning precision: +/- 20 µm (0.8 Mil)
Smallest drilling diameter: 0.2 mm (8 Mil)
