Care and maintenance

Operating Manual 7.1 Rev.: 18.06.2008 117

III. Cleaning the collet chuck and the collet chuck holder

1. Insert the collet chuck brush into the collet chuck and push/turn the

brush repeatedly to remove the dust particles.

2. Clean the exterior of the collet chuck with a brush.

3. Insert the collet chuck brush into the collet chuck holder on the mill-

ing/drilling head and push/turn the brush repeatedly to remove the

dust particles.

NOT use any cleaning agents.The collet chuck holder must

NOT be degreased.

[ ] The cleaning of the collet chuck and collet chuck holder is done.

Fig. 56: Cleaning the collet

chuck holder

Fig. 57: Cleaning the collet

chuck holder
