The traversing table

32 ProtoMat

S62

3.2 The traversing table

The traversing table can be moved in the Y direction to position the mill-

ing/drilling head in any position above the work area. BoardMaster co-

ordinates the traversing motions.

Note: The circuit board plotter can be equipped with the optionally available vac-

uum table.

Fig. 13: Pass hole system

1 Pass hole strip (red)

2 Pass hole pin

3 Traversing table
