64 ProtoMat
®
S62
4.6 Loading
To avoid material damage, the circuit board plotter must only be loaded in
the pause position.
4.6.1 Loading and setting up the base material
The circuit board plotter has been designed for the use of base materials
with pass holes. We recommend the use of pre-drilled base materials at
all times. If your base material has no pass holes, you must drill them first
(see chapter ‚ "Drilling pass holes into the drilling underlay", on page 80).
Loading base material
1. Click on the Move to pause button in order to load the traversing
table.
2. Remove any material swarf from the traversing table with a soft
brush or a moistened cloth.
3. Set the drilling underlay down on the traversing table so that the
pass hole pins slot into the pass holes.
4. Set the base material down on the drilling underlay with the side to
be processed facing up so that the pass hole pins slot into the pass
holes.
5. Make sure that the pass hole pins do not protrude out of the base
material.
6. Using a non-residue adhesive tape, stick the edges of the base
material to the drilling underlay.
[ ] Now you can set up the work area.
WARNING
Health hazard!
The swarf and dust generated during material processing can
cause eye injuries and allergies.
› Extract the swarf and dust or remove them with a brush or mois-
tened cloth. N
EVER blow compressed air through the acoustic
cabinet.
