What you should know
Operating Manual 7.1 Rev.: 18.06.2008 41
3.7 Automatic operation
In automatic mode, the CAD data prepared with CircuitCAM is used for
production. These *.LMD files contain information regarding layout, struc-
ture and use of the required tools.
3.7.1 Production types and phase files
The following production types can be produced using the phase files
included in the scope of delivery:
Tab. 2: Production types and phase files
As the ProtoMat
®
S62 is factory-set to produce single-sided/double-sided
printed circuit boards followed by galvanic through-hole plating, it is not
necessary to select a phase file for this production type. Phase file
1-2layer.phs (<default>) is used.
Tip: Use the tutorial files prepared by LPKF to familiarise yourself with
the automatic operation and to produce a double-sided sample circuit
board. Detailed information about the tutor data can be found in the
tutorial ProtoMat
®
S62 Tutor data.
Production type Phase file
Single-sided/double-sided printed circuit
boards
(galvanic through-hole plating)
1-2layer.phs (<default>)
Single-sided/double-sided printed circuit
boards
(galvanic through-hole plating with LPKF
ProConduct)
1-2layer + proconduct.phs
4-layer multi-layer
(galvanic through-hole plating)
4-layer.phs
4-layer multi-layer
(galvanic through-hole plating with LPKF
ProConduct)
4-layer + proconduct.phs
6-layer multi-layer 6-layer.phs
Solder stop foils soldermask.phs
Solder paste stencils stencilmilling.phs
