4.11 Creating a pass hole system (basic equipment)
The ProtoMat
®
S62 traversing table is factory-set with a pass hole sys-
tem for standard material sizes (9" x 12"). If, after a period of time, the
pass hole pins are not seated free of play anymore, you will need to cre-
ate a new pass hole system. You will also need to do this if you wish to
process materials of smaller dimensions.
Required tool and acces-
sories
To create the pass hole system in the traversing table, you will need the
following tool and accessories:
• Spiral Drill Ref. 2.95 mm
for pass holes in the plastic strips on the traversing table.
• Spiral Drill .3.0 mm:
for pass holes in the drilling underlay and in the base material
• Pass hole pins 3 mm x 8 mm
• Press-in tool for pass hole pins
• Combined collet for removing existing pass hole pins
You must remember that the procedures for drilling pass holes in the tra-
versing table (see "Preparation" on page 65) differ from those for the vac-
uum table (see "Creating a pass hole system (vacuum table)" on
page 69).
Conditions The following information assumes that the Spiral Drill Ref 2.95 mm and
Spiral Drill .3.0 mm tools have been set up in BoardMaster and loaded in
the tool magazine accordingly. (see chapter 4.6.2‚ "Setting up tools", on
page 67)
To drill pass holes into the plastic strips on the traversing table, proceed
as follows:
I.
Preparing the circuit board plotter
1. Dismount the plastic base/brush head from the milling depth limiter
(see "Dismounting the plastic base/brush head" on page 62).
2. Click on the Move to pause button in order to move the traversing
table to the loading position.
