Manual operation

40 ProtoMat

S62

Use For tool-friendly material removal/contour milling, the 2.5 D function

should be used with the following materials/milling depths:

Tab. 1: 2.5 D processing, milling depth and materials

3.6 Manual operation

The manual operation is used primarily for creating individual bores and

structures, for post-processing printed circuit boards manufactured auto-

matically and for special applications.

Manual operation supplements the automatic functions and can be exe-

cuted at any time.

Material Milling depth

GFK (FR4)/CFK base material

PTFE/ceramic composite base material

>2mm

Wood

Non-ferrous metals (aluminium, brass)

>0.25mm

Plastics (polyoxymethylenes, ABS copolymers
