Tab. 6: Production types and phase files
[ ] The required production phases are displayed in the phase selection (see
Tab. 3 "Production phases" on page 40).
5.3 Setting up a job
A job contains all data and information required for production. You can
open and edit an existing job, or create a new one.
Note: The items listed below correspond to the standard production of a single-
sided or double-sided printed circuit board with galvanic through-hole plating
(1-2layer.phs).
To set up a new job, you first need to import a project (LMD file). How-
ever, you can also open an existing job and add further projects to it.
Information about the
example files
• You can use the Tutor.LMD project to produce a double-sided prac-
tice printed circuit board.
• Fiducial.LMD contains information for drilling a fiducial (only needed
if you are using the VisionSystem).
Production type Phase file
Single-sided/double-sided printed circuit
boards
(galvanic through-hole plating)
1-2layer.phs (<default>)
Single-sided/double-sided printed circuit
boards
(galvanic through-hole plating with LPKF
ProConduct)
1-2layer + proconduct.phs
4-layer multi-layer
(galvanic through-hole plating)
4-layer.phs
4-layer multi-layer
(galvanic through-hole plating with LPKF
ProConduct)
4-layer + proconduct.phs
6-layer multi-layer 6-layer.phs
Solder stop foils soldermask.phs
Solder paste stencils stencilmilling.phs
