4. In the tool magazine window, click on Accept.
The co-ordinates determined are applied to the changing position.
5. Repeat the test and correction functions as necessary for all tool
positions.
6. Click on OK to close the Tool magazine window.
7. Move the milling/drilling head to the pause position.
8. Remove the measuring insert from the tool magazine.
9. Exit BoardMaster and restart the program to apply the values
saved in the INI file.
[ ] The configuration of the tool changing positions is complete.
6.5 Adjusting the camera (only with VisionSystem)
If the camera image on the monitor is not focussed, you will need to reset
the focus (see chapter 3.6 "Setting the focus (VisionSystem only)" on
page 59).
The camera offset between the milling/drilling position and the centre of
the camera image must be recalculated if the positioning of the mill-
ing/drilling head with the camera produces incorrect results.
Automatic fiducial recognition is factory-set for bores 1.5 mm in diameter.
The fiducial recognition must be calibrated if BoardMaster does not rec-
ognize the fiducials or if a different drill diameter needs to be used.
