Working sequence in automatic mode
Operating Manual 7.1 Rev.: 18.06.2008 103
– Click on the - button.
All data segments inside the selected area including all associated sege-
ments are deactivated.
2. To deactivate the data segments within an area only:
– Click on the Add segments button.
– With the left mouse button pressed draw up the area to be deacti-
vated .
– Click on the - button.
[ ] All segments in the selected area are deactivated.
5.6 Setting up 2.5 D processing (optional)
Conditions:
• The plastic base of the milling depth limiter is replaced with the LPKF
brush head, which is available as an accessory (see chapter 4.5‚
"Mounting/Dismounting the milling depth limiter base", on page 62).
• For surface processing the vacuum table (option) must be installed.
• The option Stop for depth adjustment in the Tool Positions win-
dow is activated.
Consider the different approaches of 2.5 D-processing according to the
working aim and equipment of the circuit board plotter.
