Selecting a tool for processing
70 ProtoMat
®
S62
4.6.3 Inserting tools
Inserting tools
1. With the tip pointing downwards, push the desired tools as far as
they will go into the tool holders defined in the Tool positions win-
dow (Pos.).
Note: Position 1 is on the left-hand side of the tool magazine, position 10
is on the right.
2. Close the acoustic cabinet cover.
3. Click on OK.
4.7 Selecting a tool for processing
To create a bore or milling track, you need to have set up the desired tool
and inserted it into the correct position in the tool magazine. The tools
currently set up are displayed in the tool selection list. The number in
front of the tool name corresponds to the position in the tool magazine.
WARNING
Risk of injury!
The tools to be used are very sharp edged and can cause cuts
and stab injuries.
› Handle tools carefully and keep them in the toolbox when not in
use.
CAUTION
Material damage due to incorrect loading!
If you insert the tools into other positions than those defined by
BoardMaster, the milling/drilling head and spindle and the tools
can become damaged.
› Insert the tools only into the tool holder (positions) defined in
BoardMaster.
