Manual tasks and settings
Operating Manual 7.1 Rev.: 18.06.2008 81
11. Click on the Lower head button to drill the pass hole.
12. Click on the Motor off button.
[ ] To complete the pass hole system, you simply need to insert the pass hole
pins (see chapter 4.13‚ "Inserting pass hole pins", on page 88) and mount
the plastic base on the milling depth limiter(see "Mounting the plastic
base/brush head").
4.12 Creating a pass hole system for the vacuum table
The scope of delivery of the vacuum table does not include a pass hole
system. To create the pass hole system, you will need the following tool
and accessories:
Required tool
and accessories
• Spiral Drill Ref. 2.95 mm
To drill the pass holes into the plastic strips and the vacuum table's
sinter plate
• Spiral Drill .3.0 mm:
To drill the pass holes into the base material (optional)
• Pass hole pins 3 mm x 10 mm
• Press-in tool for pass hole pins
The following information assumes that the Spiral Drill Ref 2.95 mm and
Spiral Drill .3.0 mmtools have been set up in BoardMaster and loaded in
the tool magazine accordingly (see chapter 4.6.2‚ "Setting up tools", on
page 67).
