Milling
74 ProtoMat
®
S62
5. Move the milling/drilling head as necessary to drill more holes with
the same drill.
or:
Click on the Motor off button.
[ ] The milling/drilling spindle and the dust extraction (automatic mode only)
are switched off.
4.10 Milling
Please note that milling results are dependent upon tool penetration
depth. Insufficient material removal between the later conductor tracks
can cause the circuit board to malfunction. In the case of the Universal
Cutter and Micro Cutter conical mills, milling width is determined by pene-
tration depth.
Always carry out a test milling on the base material to be used and check
the milling depth with a microscope to confirm sufficient material removal.
In order to ensure the desired milling width when using the Universal Cut-
ter or Micro Cutter mills, you should check this with a measuring micro-
scope.
Correct the milling depth if necessary before continuing work (see
chapter ‚ "Adjusting the milling depth/width", on page 76).
WARNING
Health hazard!
The processing of the materials can give rise to dusts and gases
hazardous to your health.
› You must switch on the dust extraction before processing mate-
rials. Extract the dust and material residues or remove them
with a brush or moistened cloth; do
NOT blow compressed air
through.
