Working sequence in automatic mode
Operating Manual 7.1 Rev.: 18.06.2008 109
5.7.1 Stopping the production phase
A production phase can be interrupted at any time and resumed subse-
quently. Production based on data already sent to the circuit board plotter
will be completed.
Interrupting the production phase
1. Click on Stop once.
If the production phase is not interrupted immediately, wait until all
data already sent has been processed.
If you click on Stop again, the production phase will be resumed
immediately and more data will be sent to the circuit board plotter.
The production phase is interrupted, no more data is sent to the circuit
board plotter. Once the circuit board plotter has processed the data
already sent to it, you can execute manual operating steps, for example
reworking of individual lines.
2. To continue the production phase:
Click on Start.
The production phase continues with the activated data.
3. To end the production phase:
Select another production phase from the phase selection list.
[]
5.8 Ending production
Production can be brought to an end at any time. You can save the cur-
rent processing status and resume production subsequently or abort pro-
duction.
Saving the production status
1. If the plotter is still working:
Click on Stop.
No more data is transmitted to the circuit board plotter. Production based
on data already sent will be completed.
