Usable tools

36 ProtoMat

S62

End Mill (End Mill 1/8")

RF end mill (End Mill (RF)

1/8")

Application:

Aluminium engraving, recesses and wide insula-

tion clearances

Colour:

Purple

Shape:

Cylindrical

Milling widths:

d = 0.80 mm (31 mil)

d = 1.00 mm (39 mil)

d = 2.00 mm (79 mil)

d = 3.00 mm (118 mil)

0.8-3.0mm

(31-118mil)

Copper

0.8-3.0mm

(31-118mil)

Aluminium

Application:

Smallest insulation clearances in RF materials.

Colour:

Blue

Shape:

Cylindrical

Milling widths:

d = 0.15 mm (6 mil)

d = 0.25 mm (10 mil)

d = 0.4 mm (16 mil)

0.5-0.4mm

(6 - 16 mil)

Copper
