Register 6-10: IEC2: Interrupt Enable Control Register 2
Upper Byte:
U-0 U-0 U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
— — — FLTBIE FLTAIE LVDIE DCIIE QEIIE
bit 15 bit 8
Lower Byte:
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
PWMIE C2IE INT4IE INT3IE OC8IE OC7IE OC6IE OC5IE
bit 7 bit 0
bit 15-13 Unimplemented: Read as ‘0’
bit 12 FLTBIE: Fault B Input Interrupt Enable bit
1 = Interrupt request enabled
0 = Interrupt request not enabled
bit 11 FLTAIE: Fault A Interrupt Enable bit
1 = Interrupt request enabled
0 = Interrupt request not enabled
bit 10 LVDIE: Programmable Low Voltage Detect Interrupt Enable bit
1 = Interrupt request enabled
0 = Interrupt request not enabled
bit 9 DCIIE: Data Converter Interface Interrupt Enable bit
1 = Interrupt request enabled
0 = Interrupt request not enabled
bit 8 QEIIE: Quadrature Encoder Interface Interrupt Enable bit
1 = Interrupt request enabled
0 = Interrupt request not enabled
bit 7 PWMIE: Motor Control Pulse Width Modulation Interrupt Enable bit
1 = Interrupt request enabled
0 = Interrupt request not enabled
bit 6 C2IE: CAN2 (Combined) Interrupt Enable bit
1 = Interrupt request enabled
0 = Interrupt request not enabled
bit 5 INT4IE: External Interrupt 4 Enable bit
1 = Interrupt request enabled
0 = Interrupt request not enabled
bit 4 INT3IE: External Interrupt 3 Enable bit
1 = Interrupt request enabled
0 = Interrupt request not enabled
bit 3 OC8IE: Output Compare Channel 8 Interrupt Enable bit
1 = Interrupt request enabled
0 = Interrupt request not enabled
bit 2 OC7IE: Output Compare Channel 7 Interrupt Enable bit
1 = Interrupt request enabled
0 = Interrupt request not enabled
